Cost-effectiveness decision for fixing a known coding mistake

Derek Jones from The Shape of Code

If a mistake is spotted in the source code of a shipping software system, is it more cost-effective to fix the mistake, or to wait for a customer to report a fault whose root cause turns out to be that particular coding mistake?

The naive answer is don’t wait for a customer fault report, based on the following simplistic argument: C_{fix} < C_{find}+C_{fix}.

where: C_{fix} is the cost of fixing the mistake in the code (including testing etc), and C_{find} is the cost of finding the mistake in the code based on a customer fault report (i.e., the sum on the right is the total cost of fixing a fault reported by a customer).

If the mistake is spotted in the code for ‘free’, then C_{find}==0, e.g., a developer reading the code for another reason, or flagged by a static analysis tool.

This answer is naive because it fails to take into account the possibility that the code containing the mistake is deleted/modified before any customers experience a fault caused by the mistake; let M_{gone} be the likelihood that the coding mistake ceases to exist in the next unit of time.

The more often the software is used, the more likely a fault experience based on the coding mistake occurs; let F_{experience} be the likelihood that a fault is reported in the next time unit.

A more realistic analysis takes into account both the likelihood of the coding mistake disappearing and a corresponding fault being reported, modifying the relationship to: C_{fix} < (C_{find}+C_{fix})*{F_{experience}/M_{gone}}

Software systems are eventually retired from service; the likelihood that the software is maintained during the next unit of time, S_{maintained}, is slightly less than one.

Giving the relationship: C_{fix} < (C_{find}+C_{fix})*{F_{experience}/M_{gone}}*S_{maintained}

which simplifies to: 1 < (C_{find}/C_{fix}+1)*{F_{experience}/M_{gone}}*S_{maintained}

What is the likely range of values for the ratio: C_{find}/C_{fix}?

I have no find/fix cost data, although detailed total time is available, i.e., find+fix time (with time probably being a good proxy for cost). My personal experience of find often taking a lot longer than fix probably suffers from survival of memorable cases; I can think of cases where the opposite was true.

The two values in the ratio F_{experience}/M_{gone} are likely to change as a system evolves, e.g., high code turnover during early releases that slows as the system matures. The value of F_{experience} should decrease over time, but increase with a large influx of new users.

A study by Penta, Cerulo and Aversano investigated the lifetime of coding mistakes (detected by several tools), tracking them over three years from creation to possible removal (either fixed because of a fault report, or simply a change to the code).

Of the 2,388 coding mistakes detected in code developed over 3-years, 41 were removed as reported faults and 416 disappeared through changes to the code: F_{experience}/M_{gone} = 41/416 = 0.1

The plot below shows the survival curve for memory related coding mistakes detected in Samba, based on reported faults (red) and all other changes to the code (blue/green, code+data):

Survival curves of coding mistakes in Samba.

Coding mistakes are obviously being removed much more rapidly due to changes to the source, compared to customer fault reports.

For it to be cost-effective to fix coding mistakes in Samba, flagged by the tools used in this study (S_{maintained} is essentially one), requires: 10 < C_{find}/C_{fix}+1.

Meeting this requirement does not look that implausible to me, but obviously data is needed.

semgrep: the future of static analysis tools

Derek Jones from The Shape of Code

When searching for a pattern that might be present in source code contained in multiple files, what is the best tool to use?

The obvious answer is grep, and grep is great for character-based pattern searches. But patterns that are token based, or include information on language semantics, fall outside grep‘s model of pattern recognition (which does not stop people trying to cobble something together, perhaps with the help of complicated sed scripts).

Those searching source code written in C have the luxury of being able to use Coccinelle, an industrial strength C language aware pattern matching tool. It is widely used by the Linux kernel maintainers and people researching complicated source code patterns.

Over the 15+ years that Coccinelle has been available, there has been a lot of talk about supporting other languages, but nothing ever materialized.

About six months ago, I noticed semgrep and thought it interesting enough to add to my list of tool bookmarks. Then, a few days ago, I read a brief blog post that was interesting enough for me to check out other posts at that site, and this one by Yoann Padioleau really caught my attention. Yoann worked on Coccinelle, and we had an interesting email exchange some 13-years ago, when I was analyzing if-statement usage, and had subsequently worked on various static analysis tools, and was now working on semgrep. Most static analysis tools are created by somebody spending a year or so working on the implementation, making all the usual mistakes, before abandoning it to go off and do other things. High quality tools come from people with experience, who have invested lots of time learning their trade.

The documentation contains lots of examples, and working on the assumption that things would be a lot like using Coccinelle, I jumped straight in.

The pattern I choose to search for, using semgrep, involved counting the number of clauses contained in Python if-statement conditionals, e.g., the condition in: if a==1 and b==2: contains two clauses (i.e., a==1, b==2). My interest in this usage comes from ideas about if-statement nesting depth and clause complexity. The intended use case of semgrep is security researchers checking for vulnerabilities in code, but I’m sure those developing it are happy for source code researchers to use it.

As always, I first tried building the source on the Github repo, (note: the Makefile expects a git clone install, not an unzipped directory), but got fed up with having to incrementally discover and install lots of dependencies (like Coccinelle, the code is written on OCaml {93k+ lines} and Python {13k+ lines}). I joined the unwashed masses and used pip install.

The pattern rules have a yaml structure, specifying the rule name, language(s), message to output when a match is found, and the pattern to search for.

After sorting out various finger problems, writing C rather than Python, and misunderstanding the semgrep output (some of which feels like internal developer output, rather than tool user developer output), I had a set of working patterns.

The following two patterns match if-statements containing a single clause (if.subexpr-1), and two clauses (if.subexpr-2). The option commutative_boolop is set to true to allow the matching process to treat Python’s or/and as commutative, which they are not, but it reduces the number of rules that need to be written to handle all the cases when ordering of these operators is not relevant (rules+test).

rules:
- id: if.subexpr-1
  languages: [python]
  message: if-cond1
  patterns:
   - pattern: |
      if $COND1:  # we found an if statement
         $BODY
   - pattern-not: |
      if $COND2 or $COND3: # must not contain more than one condition
         $BODY
   - pattern-not: |
      if $COND2 and $COND3:
         $BODY
  severity: INFO

- id: if.subexpr-2
  languages: [python]
  options:
   commutative_boolop: true # Reduce combinatorial explosion of rules
  message: if-cond2
  pattern-either:
   - patterns:
      - pattern: |
         if $COND1 or $COND2: # if statement containing two conditions
            $BODY
      - pattern-not: |
         if $COND3 or $COND4 or $COND5: # must not contain more than two conditions
            $BODY
      - pattern-not: |
         if $COND3 or $COND4 and $COND5:
            $BODY
   - patterns:
      - pattern: |
         if $COND1 and $COND2:
            $BODY
      - pattern-not: |
         if $COND3 and $COND4 and $COND5:
            $BODY
      - pattern-not: |
         if $COND3 and $COND4 or $COND5:
            $BODY
  severity: INFO

The rules would be simpler if it were possible for a pattern to not be applied to code that earlier matched another pattern (in my example, one containing more clauses). This functionality is supported by Coccinelle, and I’m sure it will eventually appear in semgrep.

This tool has lots of rough edges, and is still rapidly evolving, I’m using version 0.82, released four days ago. What’s exciting is the support for multiple languages (ten are listed, with experimental support for twelve more, and three in beta). Roughly what happens is that source code is mapped to an abstract syntax tree that is common to all supported languages, which is then pattern matched. Supporting a new language involves writing code to perform the mapping to this common AST.

It’s not too difficult to map different languages to a common AST that contains just tokens, e.g., identifiers and their spelling, literals and their value, and keywords. Many languages use the same operator precedence and associativity as C, plus their own extras, and they tend to share the same kinds of statements; however, declarations can be very diverse, which makes life difficult for supporting a generic AST.

An awful lot of useful things can be done with a tool that is aware of expression/statement syntax and matches at the token level. More refined semantic information (e.g., a variable’s type) can be added in later versions. The extent to which an investment is made to support the various subtleties of a particular language will depend on its economic importance to those involved in supporting semgrep (Return to Corp is a VC backed company).

Outside of a few languages that have established tools doing deep semantic analysis (i.e., C and C++), semgrep has the potential to become the go-to static analysis tool for source code. It will benefit from the network effects of contributions from lots of people each working in one or more languages, taking their semgrep skills and rules from one project to another (with source code language ceasing to be a major issue). Developers using niche languages with poor or no static analysis tool support will add semgrep support for their language because it will be the lowest cost path to accessing an industrial strength tool.

How are the VC backers going to make money from funding the semgrep team? The traditional financial exit for static analysis companies is selling to a much larger company. Why would a large company buy them, when they could just fork the code (other company sales have involved closed-source tools)? Perhaps those involved think they can make money by selling services (assuming semgrep becomes the go-to tool). I have a terrible track record for making business predictions, so I will stick to the technical stuff.

Academic recognition for creating and supporting software

Derek Jones from The Shape of Code

A scientific paper is supposed to contain enough information that somebody skilled in the field can perform the experiment(s) described therein (issues around the money needed to obtain access to the necessary equipment tend to be side stepped). In addition to the skills generally taught within a field, every niche has its specific skill set, which for leading edge research may only be available in one lab.

Bespoke software has become an essential component of many research projects, and the ability to reimplement the necessary software is rarely considered to be a necessary skill. Some researchers consider software to be “just code” whose creation is not really a skill that is worth investing in acquiring.

There is a widespread belief in academic circles that the solution to the issues created by bespoke software is for researchers to release the source code of the software they create.

Experienced developers will laugh at the idea that once the source code is available, running it is straight forward. Figuring out how to run somebody else’s code can be a very time-consuming process, particularly when the person who wrote it is relatively inexperienced.

This post is about the social issues around the bespoke research code being made available, and not the technical issues likely to be encountered in building it on another researcher’s computer.

Lots of researchers do make their code available, without being asked, and some researchers actively promote the software they have written. In a few cases, active software ecosystems have sprung up around a research topic, e.g., Astropy and SunPy.

However, a lot of code never gets released. Based on my own experience of asking for code (in the last 10 years, most of my requests have been for data), reasons given by researchers for not making the code they have written available to others, include:

  • not replying to email requests for the code,
  • not sure that they still have the all code, which is taken as a reason for not sending what they have. This may also be a cover story for another reason they don’t want to admit to,
  • they don’t want the hassle of supporting other users of the code. Having received some clueless requests for help on software I have released, I have sympathy for this position. Sometimes pointing out that I am an experienced developer who does not need support, works, other times it just changes the reason given,
  • they think the code is poorly written, and that this poor of quality will make them look bad. Pointing out that research code is leading edge (rare true, it’s an attempt to stroke their ego), and not supposed to be polished, rarely works for me. Some people are just perfectionists, with a strong aversion to showing others anything that has not been polished to death,
  • a large investment was made to create the software, and they want to reap all the benefits. I have a lot of sympathy with this position. Some research fields are very competitive, or sometimes the researcher just wants to believe that they really will get another grant to work on the subject.

Researchers who create and support research software complain that they don’t get any formal recognition for this work; which begs the question: why are you working on this software when you know that you are unlikely to receive any recognition?

How might researchers receive recognition for writing, supporting and releasing code?

Citations to published papers are a commonly used technique for measuring the worth of the work done by a researcher (this metric is used when evaluating people for promotion, awarding grants, and evaluating departments), and various organizations are promoting the use of citations for software.

Some software provides enough benefits that the authors can write a conventional paper about it, e.g., a paper on Astropy (which does not cite any of the third-party packages used in its own implementation). But a lot of research software does not have sufficient general appeal to warrant a paper.

Are citations for software a good idea?

An important characteristic of any evaluation metric is how hard it is to fake a good score.

Research papers are rated by the journal in which they are published, with each journal having its own rating (a short-term metric), and the number of times the paper is cited (a longer-term metric). Papers are reviewed, with many failing to be accepted (at least by the higher quality journals; there are so-called predatory journals that will publish anything for a fee).

While there are a few journals where source code may be an integral component of a paper, most research software is published on sites having minimal acceptance criteria, e.g., Github.

Will citations to software become as commonplace as citations to other papers?

I regularly read software papers that cites software packages, but this practice is a long way from being common.

Will those awarding job promotions and grants start to include software creation as having a status comparable to published papers? We will have to wait and see.

Will the lure of recognition via citations increase the quantity of source being released?

I don’t think it will have any impact until the benefits of software citations are seen to be worthwhile (which may be many years away).

Two failed software development projects in the High Court

Derek Jones from The Shape of Code

When submitting a bid, to be awarded the contract to develop a software system, companies have to provide information on costs and delivery dates. If the costs are significantly underestimated, and/or the delivery dates woefully optimistic, one or more of the companies involved may resort to legal action.

Searching the British and Irish Legal Information Institute‘s Technology and Construction Court Decisions throws up two interesting cases (when searching on “source code”; I have not been able to figure out the patterns in the results that were not returned by their search engine {when I expected some cases to be returned}).

The estimation and implementation activities described in the judgements for these two cases could apply to many software projects, both successful and unsuccessful. Claiming that the system will be ready by the go-live date specified by the customer is an essential component of winning a bid, the huge uncertainties in the likely effort required comes as standard in the software industry environment, and discovering lots of unforeseen work after signing the contract (because the minimum was spent on the bid estimate) is not software specific.

The first case is huge (BSkyB/Sky won the case and EDS had to pay £200+ million): (1) BSkyB Limited (2) Sky Subscribers Services Limited: Claimants – and (1) HP Enterprise Services UK Limited (formerly Electronic Data Systems Limited) (2) Electronic Data systems LLC (Formerly Electronic Data Systems Corporation: Defendants. The amount bid was a lot less than £200 million (paragraph 729 “The total EDS “Sell Price” was £54,195,013 which represented an overall margin of 27% over the EDS Price of £39.4 million.” see paragraph 90 for a breakdown).

What can be learned from the judgement for this case (the letter of Intent was subsequently signed on 9 August 2000, and the High Court decision was handed down on 26 January 2010)?

  • If you have not been involved in putting together a bid for a large project, paragraphs 58-92 provides a good description of the kinds of activities involved. Paragraphs 697-755 discuss costing details, and paragraphs 773-804 manpower and timing details,
  • if you have never seen a software development contract, paragraphs 93-105 illustrate some of the ways in which delivery/payments milestones are broken down and connected. Paragraph 803 will sound familiar to developers who have worked on large projects: “… I conclude that much of Joe Galloway’s evidence in relation to planning at the bid stage was false and was created to cover up the inadequacies of this aspect of the bidding process in which he took the central role.” The difference here is that the money involved was large enough to make it worthwhile investing in a court case, and Sky obviously believed that they could only be blamed for minor implementation problems,
  • don’t have the manager in charge of the project give perjured evidence (paragraph 195 “… Joe Galloway’s credibility was completely destroyed by his perjured evidence over a prolonged period.”). Bringing the law of deceit and negligent misrepresentation into a case can substantially increase/decrease the size of the final bill,
  • successfully completing an implementation plan requires people with the necessary skills to do the work, and good people are a scarce resource. Projects fail if they cannot attract and keep the right people; see paragraphs 1262-1267.

A consequence of the judge’s finding of misrepresentation by EDS is a requirement to consider the financial consequences. One item of particular interest is the need to calculate the likely effort and time needed by alternative suppliers to implement the CRM System.

The only way to estimate, with any degree of confidence, the likely cost of implementing the required CRM system is to use a conventional estimation process, i.e., a group of people with the relevant domain knowledge work together for some months to figure out an implementation plan, and then cost it. This approach costs a lot of money, and ties up scarce expertise for long periods of time; is there a cheaper method?

Management at the claimant/defence companies will have appreciated that the original cost estimate is likely to be as good as any, apart from being tainted by the perjury of the lead manager. So they all signed up to using Tasseography, e.g., they get their respective experts to estimate the amount of code that needs to be produce to implement the system, calculate how long it would take to write this code and multiply by the hourly rate for a developer. I would loved to have been a fly on the wall when the respective IT experts, all experienced in provided expert testimony, were briefed. Surely the experts all knew that the ballpark figure was that of the original EDS estimate, and that their job was to come up with a lower/high figure?

What other interpretation could there be for such a bone headed approach to cost estimation?

The EDS expert based his calculation on the debunked COCOMO model (ok, my debunking occurred over six years later, but others have done it much earlier).

The Sky expert based his calculation on the use of function points, i.e., estimation function points rather than lines of code, and then multiply by average cost per function point.

The legal teams point out the flaws in the opposing team’s approach, and the judge does a good job of understanding the issues and reaching a compromise.

There may be interesting points tucked away in the many paragraphs covering various legal issues. I barely skimmed these.

The second case is not as large (the judgement contains a third the number of paragraphs, and the judgement handed down on 19 February 2021 required IBM to pay £13+ million): SCIS GENERAL INSURANCE LIMITED: Claimant – and – IBM UNITED KINGDOM LIMITED: Defendant.

Again there is lots to learn about how projects are planned, estimated and payments/deliveries structured. There are staffing issues; paragraph 104 highlights how the client’s subject matter experts are stuck in their ways, e.g., configuring the new system for how things used to work and not attending workshops to learn about the new way of doing things.

Every IT case needs claimant/defendant experts and their collection of magic spells. The IBM expert calculated that the software contained technical debt to the tune of 4,000 man hours of work (paragraph 154).

If you find any other legal software development cases with the text of the judgement publicly available, please let me know (two other interesting cases with decisions on the British and Irish Legal Information Institute).

Electronic Evidence and Electronic Signatures: book

Derek Jones from The Shape of Code

Electronic Evidence and Electronic Signatures by Stephen Mason and Daniel Seng is not the sort of book that I would normally glance at twice (based on its title). However, at this start of the year I had an interesting email conversation with the first author, who worked for the defence team on the Horizon IT project case, and he emailed with the news that the fifth edition was now available (there’s a free pdf version, so why not have a look; sorry Stephen).

Regular readers of this blog will be interested in chapter 4 (“Software code as the witness”) and chapter 5 (“The presumption that computers are ‘reliable'”).

Legal arguments are based on precedent, i.e., decisions made by judges in earlier cases. The one thing that stands from these two chapters is how few cases have involved source code and/or reliability, and how simplistic the software issues have been (compared to issues that could have been involved). Perhaps the cases involving complicated software issues get simplified by the lawyers, or they look like they will be so difficult/expensive to litigate that the case don’t make it to court.

Chapter 4 provided various definitions of source code, all based around the concept of imperative programming, i.e., the code tells the computer what to do. No mention of declarative programming, where the code specifies the information required and the computer has to figure out how to obtain it (SQL being a widely used language based on this approach). The current Wikipedia article on source code is based on imperative programming, but the programming language article is not so narrowly focused (thanks to some work by several editors many years ago 😉

There is an interesting discussion around the idea of source code as hearsay, with a discussion of cases (see 4.34) where the person who wrote the code had to give evidence so that the program output could be admitted as evidence. I don’t know how often the person who wrote the code has to give evidence, but these days code often has multiple authors, and their identity is not always known (e.g., author details have been lost, or the submission effectively came via an anonymous email).

Chapter 5 considers the common law presumption in the law of England and Wales that ‘In the absence of evidence to the contrary, the courts will presume that mechanical instruments were in order. Yikes! The fact that this is presumption is nonsense, at least for computers, was discussed in an earlier post.

There is plenty of case law discussion around the accuracy of devices used to breath-test motorists for their alcohol level, and defendants being refused access to the devices and associated software. Now, I’m sure that the software contained in these devices contains coding mistakes, but was a particular positive the result of a coding mistake? Without replicating the exact conditions occurring during the original test, it could be very difficult to say. The prosecution and Judges make the common mistake of assuming that because the science behind the test had been validated, the device must produce correct results; ignoring the fact that the implementation of the science in software may contain implementation mistakes. I have lost count of the number of times that scientist/programmers have told me that because the science behind their code is correct, the program output must be correct. My retort that there are typos in the scientific papers they write, therefore there may be typos in their code, usually fails to change their mind; they are so fixated on the correctness of the science that possible mistakes elsewhere are brushed aside.

The naivety of some judges is astonishing. In one case (see 5.44) a professor who was an expert in mathematics, physics and computers, who had read the user manual for an application, but had not seen its source code, was considered qualified to give evidence about the operation of the software!

Much of chapter 5 is essentially an overview of software reliability, written by a barrister for legal professionals, i.e., it is not always a discussion of case law. A barristers’ explanation of how software works can be entertainingly inaccurate, but the material here is correct in a broad brush sense (and I did not spot any entertainingly inaccuracies).

Other than breath-testing, the defence asking for source code is rather like a dog chasing a car. The software for breath-testing devices is likely to be small enough that one person might do a decent job of figuring out how it works; many software systems are not only much, much larger, but are dependent on an ecosystem of hardware/software to run. Figuring out how they work will take multiple (expensive expert) people a lot of time.

Legal precedents are set when both sides spend the money needed to see a court case through to the end. It’s understandable why the case law discussed in this book is so sparse and deals with relatively simple software issues. The costs of fighting a case involving the complexity of modern software is going to be astronomical.

Mutation testing: its days in the limelight are over

Derek Jones from The Shape of Code

How good a job does a test suite do in detecting coding mistakes in the program it tests?

Mutation testing provides one answer to this question. The idea behind mutation testing is to make a small change to the source code of the program under test (i.e., introduce a coding mistake), and then run the test suite through the mutated program (ideally one or more tests fail, as-in different behavior should be detected); rinse and repeat. The mutation score is the percentage of mutated programs that cause a test failure.

While Mutation testing is 50-years old this year (although the seminal paper/a> did not get published until 1978), the computing resources needed to research it did not start to become widely available until the late 1980s. From then, Until fuzz testing came along, mutation testing was probably the most popular technique studied by testing researchers. A collected bibliography of mutation testing lists 417 papers and 16+ PhD thesis (up to May 2014).

Mutation testing has not been taken up by industry because it tells managers what they already know, i.e., their test suite is not very good at finding coding mistakes.

Researchers concluded that the reason industry had not adopted mutation testing was that it was too resource intensive (i.e., mutate, compile, build, and run tests requires successively more resources). If mutation testing was less resource intensive, then industry would use it (to find out faster what they already knew).

Creating a code mutant is not itself resource intensive, e.g., randomly pick a point in the source and make a random change. However, the mutated source may not compile, or the resulting mutant may be equivalent to one created previously (e.g., the optimised compiled code is identical), or the program takes ages to compile and build; techniques for reducing the build overhead include mutating the compiler intermediate form and mutating the program executable.

Some changes to the source are more likely to be detected by a test suite than others, e.g., replacing <= by > is more likely to be detected than replacing it by < or ==. Various techniques for context dependent mutations have been proposed, e.g., handling of conditionals.

While mutation researchers were being ignored by industry, another group of researchers were listening to industry's problems with testing; automatic test case generation took off. How might different test case generators be compared? Mutation testing offers a means of evaluating the performance of tools arrived on the scene (in practice, many researchers and tool vendors cite statement or block coverage numbers).

Perhaps industry might have to start showing some interest in mutation testing.

A fundamental concern is the extent to which mutation operators modify source in a way that is representative of the kinds of mistakes made by programmers.

The competent programmer hypothesis is often cited, by researchers, as the answer to this question. The hypothesis is that competent programmers write code/programs that is close to correct; the implied conclusion being that mutations, which are small changes, must therefore be like programmer mistakes (the citation often given as the source of this hypothesis discusses data selection during testing, but does mention the term competent programmer).

Until a few years ago, most analysis of fixes of reported faults looked at what coding constructs were involved in correcting the source code, e.g., 296 mistakes in TeX reported by Knuth. This information can be used to generate a probability table for selecting when to mutate one token into another token.

Studies of where the source code was changed, to fix a reported fault, show that existing mutation operators are not representative of a large percentage of existing coding mistakes; for instance, around 60% of 290 source code fixes to AspectJ involved more than one line (mutations usually involve a single line of source {because they operate on single statements and most statements occupy one line}), another study investigating many more fixes found only 10% of fixes involved one line, and similar findings for a study of C, Java, Python, and Haskell (a working link to the data, which is a bit of a mess).

These studies, which investigated the location of all the source code that needs to be changed, to fix a mistake, show that existing mutation operators are not representative of most human coding mistakes. To become representative, mutation operators need to be capable of making coupled changes across multiple lines/functions/methods and even files.

While arguments over the validity of the competent programmer hypothesis rumble on, the need for multi-line changes remains.

Given the lack of any major use-cases for mutation testing, it does not look like it is worth investing lots of resources on this topic. Researchers who have spent a large chunk of their career working on mutation testing will probably argue that you never know what use-cases might crop up in the future. In practice, mutation research will probably fade away because something new and more interesting has come along, i.e., fuzz testing.

There will always be niche use-cases for mutation. For instance, how likely is it that a random change to the source of a formal proof will go unnoticed by its associated proof checker (i.e., the proof checking tool output remains unchanged)?

A study based on mutating the source of Coq verification projects found that 7% of mutations had no impact on the results.

Mutation testing: its days in the limelight are over

Derek Jones from The Shape of Code

How good a job does a test suite do in detecting coding mistakes in the program it tests?

Mutation testing provides one answer to this question. The idea behind mutation testing is to make a small change to the source code of the program under test (i.e., introduce a coding mistake), and then run the test suite through the mutated program (ideally one or more tests fail, as-in different behavior should be detected); rinse and repeat. The mutation score is the percentage of mutated programs that cause a test failure.

While Mutation testing is 50-years old this year (although the seminal paper did not get published until 1978), the computing resources needed to research it did not start to become widely available until the late 1980s. From then, until fuzz testing came along, mutation testing was probably the most popular technique studied by testing researchers. A collected bibliography of mutation testing lists 417 papers and 16+ PhD thesis (up to May 2014).

Mutation testing has not been taken up by industry because it tells managers what they already know, i.e., their test suite is not very good at finding coding mistakes.

Researchers concluded that the reason industry had not adopted mutation testing was that it was too resource intensive (i.e., mutate, compile, build, and run tests requires successively more resources). If mutation testing was less resource intensive, then industry would use it (to find out faster what they already knew).

Creating a code mutant is not itself resource intensive, e.g., randomly pick a point in the source and make a random change. However, the mutated source may not compile, or the resulting mutant may be equivalent to one created previously (e.g., the optimised compiled code is identical), or the program takes ages to compile and build; techniques for reducing the build overhead include mutating the compiler intermediate form and mutating the program executable.

Some changes to the source are more likely to be detected by a test suite than others, e.g., replacing <= by > is more likely to be detected than replacing it by < or ==. Various techniques for context dependent mutations have been proposed, e.g., handling of conditionals.

While mutation researchers were being ignored by industry, another group of researchers were listening to industry's problems with testing; automatic test case generation took off. How might different test case generators be compared? Mutation testing offers a means of evaluating the performance of tools that arrived on the scene (in practice, many researchers and tool vendors cite statement or block coverage numbers).

Perhaps industry might have to start showing some interest in mutation testing.

A fundamental concern is the extent to which mutation operators modify source in a way that is representative of the kinds of mistakes made by programmers.

The competent programmer hypothesis is often cited, by researchers, as the answer to this question. The hypothesis is that competent programmers write code/programs that is close to correct; the implied conclusion being that mutations, which are small changes, must therefore be like programmer mistakes (the citation often given as the source of this hypothesis discusses data selection during testing, but does mention the term competent programmer).

Until a few years ago, most analysis of fixes of reported faults looked at what coding constructs were involved in correcting the source code, e.g., 296 mistakes in TeX reported by Knuth. This information can be used to generate a probability table for selecting when to mutate one token into another token.

Studies of where the source code was changed, to fix a reported fault, show that existing mutation operators are not representative of a large percentage of existing coding mistakes; for instance, around 60% of 290 source code fixes to AspectJ involved more than one line (mutations usually involve a single line of source {because they operate on single statements and most statements occupy one line}), another study investigating many more fixes found only 10% of fixes involved one line, and similar findings for a study of C, Java, Python, and Haskell (a working link to the data, which is a bit disjointed of a mess).

These studies, which investigated the location of all the source code that needs to be changed, to fix a mistake, show that existing mutation operators are not representative of most human coding mistakes. To become representative, mutation operators need to be capable of making coupled changes across multiple lines/functions/methods and even files.

While arguments over the validity of the competent programmer hypothesis rumble on, the need for multi-line changes remains.

Given the lack of any major use-cases for mutation testing, it does not look like it is worth investing lots of resources on this topic. Researchers who have spent a large chunk of their career working on mutation testing will probably argue that you never know what use-cases might crop up in the future. In practice, mutation research will probably fade away because something new and more interesting has come along, i.e., fuzz testing.

There will always be niche use-cases for mutation. For instance, how likely is it that a random change to the source of a formal proof will go unnoticed by its associated proof checker (i.e., the proof checking tool output remains unchanged)?

A study based on mutating the source of Coq verification projects found that 7% of mutations had no impact on the results.

Code bureaucracy can reduce the demand for cognitive resources

Derek Jones from The Shape of Code

A few weeks ago I discussed why I thought that research code was likely to remain a tangled mess of spaghetti code.

Everybody’s writing, independent of work-place, starts out as a tangled mess of spaghetti code; some people learn to write code in a less cognitively demanding style, and others stick with stream-of-conscious writing.

Why is writing a tangled mess of spaghetti code (sometimes) not cost-effective, and what are the benefits in making a personal investment in learning to write code in another style?

Perhaps the defining characteristic of a tangled mess of spaghetti code is that everything appears to depend on everything else, consequently: working out the impact of a change to some sequence of code requires an understanding of all the other code (to find out what really does depend on what).

When first starting to learn to program, the people who can hold the necessary information on increasing amounts of code in their head are the ones who manage to create running (of sorts) programs; they have the ‘knack’.

The limiting factor for an individual’s software development is the amount of code they can fit in their head, while going about their daily activities. The metric ‘code that can be fitted in a person’s head’ is an easy concept to grasp, but its definition in terms of the cognitive capacity to store, combine and analyse information in long term memory and the episodic memory of earlier work is difficult to pin down. The reason people live a monks existence when single-handedly writing 30-100 KLOC spaghetti programs (the C preprocessor Richard Stallman wrote for gcc is a good example), is that they have to shut out all other calls on their cognitive resources.

Given time, and the opportunity for some trial and error, a newbie programmer who does not shut their non-coding life down can create, say, a 1,000+ LOC program. Things work well enough, what is the problem?

The problems start when the author stops working on the code for long enough for them to forget important dependencies; making changes to the code now causes things to mysteriously stop working. Our not so newbie programmer now has to go through the frustrating and ego-denting experience of reacquainting themselves with how the code fits together.

There are ways of organizing code such that less cognitive resources are needed to work on it, compared to a tangled mess of spaghetti code. Every professional developer has a view on how best to organize code, what they all have in common is a lack of evidence for their performance relative to other possibilities.

Code bureaucracy does not sound like something that anybody would want to add to their program, but it succinctly describes the underlying principle of all the effective organizational techniques for code.

Bureaucracy compartmentalizes code and arranges the compartments into some form of hierarchy. The hoped-for benefit of this bureaucracy is a reduction in the cognitive resources needed to work on the code. Compartmentalization can significantly reduce the amount of a program’s code that a developer needs to keep in their head, when working on some functionality. It is possible for code to be compartmentalized in a way that requires even more cognitive resources to implement some functionality than without the bureaucracy. Figuring out the appropriate bureaucracy is a skill that comes with practice and knowledge of the application domain.

Once a newbie programmer is up and running (i.e., creating programs that work well enough), they often view the code bureaucracy approach as something that does not apply to them (and if they rarely write code, it might not apply to them). Stream of conscious coding works for them, why change?

I have seen people switch to using code bureaucracy for two reasons:

  • peer pressure. They join a group of developers who develop using some form of code bureaucracy, and their boss tells them that this is the way they have to work. In this case there is the added benefit of being able to discuss things with others,
  • multiple experiences of the costs of failure. The costs may come from the failure to scale a program beyond some amount of code, or having to keep investing in learning how previously written programs work.

Code bureaucracy has many layers. At the bottom there is splitting code up into functions/methods, then at the next layer related functions are collected together into files/classes, then the layers become less generally agreed upon (different directories are often involved).

One of the benefits of bureaucracy, from the management perspective, is interchangeability of people. Why would somebody make an investment in code bureaucracy if they were not the one likely to reap the benefit?

A claimed benefit of code bureaucracy is ease of wholesale replacement of one compartment by a new one. My experience, along with the little data I have seen, suggests that major replacement is rare, i.e., this is not a commonly accrued benefit.

Another claimed benefit of code bureaucracy is that it makes programs easier to test. What does ‘easier to test’ mean? I have seen reliable programs built from spaghetti code, and unreliable programs packed with code bureaucracy. A more accurate claim is that it can be unexpectedly costly to test programs built from spaghetti code after they have been changed (because of the greater likelihood of the changes having unexpected consequences). A surprising number of programs built from spaghetti code continue to be used in unmodified form for years, because nobody dare risk the cost of checking that they continue to work as expected after a modification

Source code discovery, skipping over the legal complications

Derek Jones from The Shape of Code

The 2020 US elections introduced the issue of source code discovery, in legal cases, to a wider audience. People wanted to (and still do) check that the software used to register and count votes works as intended, but the companies who wrote the software wouldn’t make it available and the courts did not compel them to do so.

I was surprised to see that there is even a section on “Transfer of or access to source code” in the EU-UK trade and cooperation agreement, agreed on Christmas Eve.

I have many years of experience in discovering problems in the source code of programs I did not write. This experience derives from my time as a compiler implementer (e.g., a big customer is being held up by a serious issue in their application, and the compiler is being blamed), and as a static analysis tool vendor (e.g., managers want to know about what serious mistakes may exist in the code of their products). In all cases those involved wanted me there, I could talk to some of those involved in developing the code, and there were known problems with the code. In court cases, the defence does not want the prosecution looking at the code, and I assume that all conversations with the people who wrote the code goes via the lawyers. I have intentionally stayed away from this kind of work, so my practical experience of working on legal discovery is zero.

The most common reason companies give for not wanting to make their source code available is that it contains trade-secrets (they can hardly say that it’s because they don’t want any mistakes in the code to be discovered).

What kind of trade-secrets might source code contain? Most code is very dull, and for some programs the only trade-secret is that if you put in the implementation effort, the obvious way of doing things works, i.e., the secret sauce promoted by the marketing department is all smoke and mirrors (I have had senior management, who have probably never seen the code, tell me about the wondrous properties of their code, which I had seen and knew that nothing special was present).

Comments may detail embarrassing facts, aka trade-secrets. Sometimes the code interfaces to a proprietary interface format that the company wants to keep secret, or uses some formula that required a lot of R&D (management gets very upset when told that ‘secret’ formula can be reverse engineered from the executable code).

Why does a legal team want access to source code?

If the purpose is to check specific functionality, then reading the source code is probably the fastest technique. For instance, checking whether a particular set of input values can cause a specific behavior to occur, or tracing through the logic to understand the circumstances under which a particular behavior occurs, or in software patent litigation checking what algorithms or formula are being used (this is where trade-secret claims appear to be valid).

If the purpose is a fishing expedition looking for possible incorrect behaviors, having the source code is probably not that useful. The quantity of source contained in modern applications can be huge, e.g., tens to hundreds of thousands of lines.

In ancient times (i.e., the 1970s and 1980s) programs were short (because most computers had tiny amounts of memory, compared to post-2000), and it was practical to read the source to understand a program. Customer demand for more features, and the fact that greater storage capacity removed the need to spend time reducing code size, means that source code ballooned. The following plot shows the lines of code contained in the collected algorithms of the Transactions on Mathematical Software, the red line is a fitted regression model of the form: LOC approx e^{0.0003Day}(code+data):

Lines of code contained in the collected algorithms of the Transactions on Mathematical Software, over time.

How, by reading the source code, does anybody find mistakes in a 10+ thousand line program? If the program only occasionally misbehaves, finding a coding mistake by reading the source is likely to be very very time-consuming, i.e, months. Work it out yourself: 10K lines of code is around 200 pages. How long would it take you to remember all the details and their interdependencies of a detailed 200-page technical discussion well enough to spot an inconsistency likely to cause a fault experience? And, yes, the source may very well be provided as a printout, or as a pdf on a protected memory stick.

From my limited reading of accounts of software discovery, the time available to study the code may be just days or maybe a week or two.

Reading large quantities of code, to discover possible coding mistakes, are an inefficient use of human time resources. Some form of analysis tool might help. Static analysis tools are one option; these cost money and might not be available for the language or dialect in which the source is written (there are some good tools for C because it has been around so long and is widely used).

Character assassination, or guilt by innuendo is another approach; the code just cannot be trusted to behave in a reasonable manner (this approach is regularly used in the software business). Software metrics are deployed to give the impression that it is likely that mistakes exist, without specifying specific mistakes in the code, e.g., this metric is much higher than is considered reasonable. Where did these reasonable values come from? Someone, somewhere said something, the Moon aligned with Mars and these values became accepted ‘wisdom’ (no, reality is not allowed to intrude; the case is made by arguing from authority). McCabe’s complexity metric is a favorite, and I have written how use of this metric is essentially accounting fraud (I have had emails from several people who are very unhappy about me saying this). Halstead’s metrics are another favorite, and at least Halstead and others at the time did some empirical analysis (the results showed how ineffective the metrics were; the metrics don’t calculate the quantities claimed).

The software development process used to create software is another popular means of character assassination. People seem to take comfort in the idea that software was created using a defined process, and use of ad-hoc methods provides an easy target for ridicule. Some processes work because they include lots of testing, and doing lots of testing will of course improve reliability. I have seen development groups use a process and fail to produce reliable software, and I have seen ad-hoc methods produce reliable software.

From what I can tell, some expert witnesses are chosen for their ability to project an air of authority and having impressive sounding credentials, not for their hands-on ability to dissect code. In other words, just the kind of person needed for a legal strategy based on character assassination, or guilt by innuendo.

What is the most cost-effective way of finding reliability problems in software built from 10k+ lines of code? My money is on fuzz testing, a term that should send shivers down the spine of a defense team. Source code is not required, and the output is a list of real fault experiences. There are a few catches: 1) the software probably to be run in the cloud (perhaps the only cost/time effective way of running the many thousands of tests), and the defense is going to object over licensing issues (they don’t want the code fuzzed), 2) having lots of test harnesses interacting with a central database is likely to be problematic, 3) support for emulating embedded cpus, even commonly used ones like the Z80, is currently poor (this is a rapidly evolving area, so check current status).

Fuzzing can also be used to estimate the numbers of so-far undetected coding mistakes.

Having all the source code in one file

Derek Jones from The Shape of Code

An early, and supposedly influential, analysis of the Coronavirus outbreak was based on results from a model whose 15,000 line C implementation was contained in a single file. There has been lots of tut-tutting from the peanut gallery, about the code all being in one file rather than distributed over many files. The source on Github has been heavily reworked.

Why do programmers work with all the code in one file, rather than split across multiple files? What are the costs and benefits of having the 15K of source in one file, compared to distributing it across multiple files?

There are two kinds of people who work with code all in one file, novices and really capable developers. Richard Stallman is an example of a very capable developer who worked using files containing huge amounts of code, as anybody who looked at the early sources of gcc will be all to familiar.

The benefit of having all the code in one file is that it is easy to find stuff and make global changes. If the source is scattered over multiple files, then working on the code entails knowing which file to look in to find whatever; there is a learning curve (these days screens have lots of pixels, and editors support multiple windows with a different file in each window; I’m sure lots of readers work like this).

Many years ago, when 64K was a lot of memory, I sometimes had to do developer support: people would come to me complaining that the computer was preventing them writing a larger program. What had happened was they had hit the capacity limit of the editor. The source now had to be spread over multiple files to get over this ‘limitation’. In practice people experienced the benefits of using multiple files, e.g., editor loading files faster (because they were a lot smaller) and reduced program build time (because only the code that changed needed to be recompiled).

These days, 15K of source can be loaded or compiled in a blink of an eye (unless a really cheap laptop is being used). Computing power has significantly reduced these benefits that used to exist.

What costs might be associated with keeping all the source in one file?

Monolithic code makes sharing difficult. I don’t know anything about the development environment within which these researched worked. If there were lots of different programs using the same algorithms, or reading/writing the same file formats, then code reuse often provides a benefit that makes it worthwhile splitting off the common functionality. But then the researchers has to learn how to build a program from multiple source files, which a surprising number are unwilling to do (at least it has always been surprising to me).

Within a research group, sharing across researchers might be a possible (assuming they are making some use of the same algorithms and file formats). Involving multiple people in the ongoing evolution of software creates a need for some coordination. At the individual level it may be more cost-efficient for people to have their own private copies of the source, with savings only occurring at the group level. With software development having a low status in academia, I don’t see any of the senior researchers willingly take on a management role, for this code. Perhaps one of the people working on the code is much better than the others (it often happens), but are they going to volunteer themselves as chief dogs body for the code?

In the world of Open Source, where source code is available, cut-and-paste is rampant (along with wholesale copying of files). Working with a copy of somebody else’s source removes a dependency, and if their code works well enough, then go for it.

A cost often claimed by the peanut gallery is that having all the code in a single file is a signal of buggy code. Given that most of the programmers who do this are novices, rather than really capable developers, such code is likely to contain many mistakes. But splitting the code up into multiple files will not reduce the number of mistakes it contains, just distribute them among the files. Correlation is not causation.

For an individual developer, the main benefit of splitting code across multiple files is that it makes developers think about the structure of their code.

For multi-person projects there are the added potential benefits of reusing code, and reducing the time spent reading other people’s code (it’s no fun having to deal with 10K lines when only a few functions are of interest).

I’m not saying that the original code is good, bad, or indifferent. What I am saying is that the having all the source in one file may, or may not, be the most effective way of working. It’s complicated, and I have no problem going with the flow (and limiting the size of the source files I write), but let’s not criticise others for doing what works for them.
